Xususiyatlari
● Sozlanishi bosim bilan oziqlanadigan tekis fan havo atomizatsiya qiluvchi nozullar nozik atomizatsiyalangan buzadigan amallar, tuman yoki tuman hosil qiladi.
● Havo va suyuqlikning ish bosimi odatda 2 -3 bar.
● Sozlanishi mumkin bo'lgan oqim tezligi turli imkoniyatlarni tanlash imkonini beradi
● Sozlanishi bosim bilan oziqlanadigan tekis fan havosini atomizatsiya qiluvchi nozullar oqim tezligini, tomchi hajmini, purkagich taqsimotini va qoplanishini nozik sozlash uchun suyuqlik, atomizatsiya havosi va fan havosi bosimini mustaqil nazorat qilishni ta'minlaydi.
Umumiy ilova
1) Qoplash, sovutish, namlash
2) Gaz bilan sovutish
3) moylash, namlash
4) tuman, tuman
5) Changni bostirish
Tavsif
Model | JN |
Turi | Sozlanishi |
Spray naqsh | Yassi fan |
Ishlash usuli | Bosim |
Aralashtiring | Ichki |
Parametr
Sprayni o'rnatish | Suyuq qopqoq / Havo qopqog'i №. | Suyuqlik sig'imi (L/soat)&er; Havo sig'imi (L/min) | Spray masofasi | ||||||||||
1,5 bar (suyuqlik) | 2 bar (suyuqlik) | 3 bar (suyuqlik) | Havo bosimi (bar) | Suyuqlik bosimi (bar) | D（m) | ||||||||
Havo bosimi (bar) | Suv sig'imi | Havo sig'imi | Havo bosimi (bar) | Suv sig'imi | Havo sig'imi | Havo bosimi (bar) | Suv sig'imi | Havo sig'imi | |||||
SU13A | Suyuqlik qopqog'i 2050 / | 1.3 | 9.1 | 31 | 2.0 | 8.6 | 42 | 2.7 | 11.2 | 52 | 1.1 | 0.7 | 2.6 |
1.5 | 7.7 | 36 | 2.2 | 7.5 | 47 | 3.0 | 10.1 | 56 | 2.1 | 1.5 | 3.0 | ||
1.8 | 6.5 | 42 | 2.5 | 6.2 | 52 | 3.2 | 9.1 | 62 | 2.8 | 2.0 | 3.2 | ||
2.1 | 5.4 | 47 | 2.8 | 5.2 | 57 | 3.5 | 8.1 | 66 | 3.5 | 3.0 | 3.4 | ||
2.4 | 4.3 | 52 | 3.1 | 4.2 | 63 | 4.2 | 5.4 | 79 | 6.0 | 4.0 | 4.0 | ||
2.7 | 3.3 | 57 | 3.2 | 3.7 | 65 | 4.6 | 4.2 | 85 | - | - | - | ||
2.8 | 2.8 | 60 | 3.4 | 3.2 | 68 | 4.9 | 3.1 | 91 | - | - | - | ||
SU13 | Suyuqlik qopqog'i 2850 / | 1.4 | 14.4 | 27 | 2.1 | 13.5 | 36 | 2.7 | 19.1 | 42 | 1.1 | 0.7 | 2.1 |
1.7 | 11.9 | 32 | 24 | 11.4 | 42 | 3.0 | 17.1 | 46 | 2.1 | 1.5 | 2.4 | ||
2.0 | 9.5 | 37 | 2.7 | 9.2 | 47 | 3.2 | 15.1 | 52 | 3.0 | 2.0 | 2.6 | ||
2.1 | 8.3 | 40 | 3.0 | 7.1 | 53 | 3.5 | 13.1 | 57 | 3.5 | 3.0 | 2.7 | ||
2.2 | 7.1 | 43 | 3.2 | 5.0 | 59 | 4.2 | 8.1 | 72 | 5.6 | 4.0 | 3.2 | ||
2.4 | 6.1 | 46 | 3.4 | 4.0 | 63 | 4.6 | 5.9 | 79 | - | - | - | ||
2.5 | 5.1 | 49 | 3.5 | 3.3 | 66 | 4.9 | 4.0 | 86 | - | - | - | ||
SUN13 | Suyuq qopqoq 2850 / Havo qopqog'i 7335 | 2.0 | 10.4 | 41 | 2.4 | 11.6 | 48 | 3.1 | 15.6 | 56 | 1.4 | 0.7 | 3.0 |
2.1 | 9.3 | 45 | 2.5 | 10.4 | 51 | 3.2 | 14.6 | 59 | 2.5 | 1.5 | 3.7 | ||
2.2 | 8.2 | 48 | 2.7 | 9.4 | 54 | 3.4 | 13.7 | 62 | 3.2 | 2.0 | 4.0 | ||
2.5 | 6.1 | 55 | 3.0 | 7.3 | 61 | 3.8 | 10.8 | 71 | 3.8 | 3.0 | 4.2 | ||
2.8 | 4.3 | 62 | 3.2 | 5.5 | 68 | 4.2 | 8.5 | 82 | 5.3 | 4.0 | 4.8 | ||
3.1 | 3.0 | 69 | 3.5 | 4.1 | 75 | 4.9 | 5.2 | 98 | - | - | - | ||
3.4 | 2.0 | 75 | 3.8 | 2.9 | 81 | 6.0 | 2.3 | 120 | - | - | - | ||
SU14 | Suyuqlik qopqog'i 2850 / | 2.1 | 7.4 | 40 | 3.0 | 6.1 | 52 | 3.9 | 9.4 | 60 | 1.5 | 0.7 | 1.8 |
2.4 | 5.3 | 45 | 3.1 | 5.3 | 54 | 4.2 | 7.2 | 67 | 2.7 | 1.5 | 2.0 | ||
2.5 | 4.4 | 47 | 3.2 | 4.5 | 57 | 4.6 | 5.3 | 73 | 3.2 | 2.0 | 2.0 | ||
2.7 | 3.7 | 50 | 3.4 | 3.8 | 59 | 4.9 | 3.8 | 80 | 4.2 | 3.0 | 2.1 | ||
2.8 | 3.1 | 52 | 3.5 | 3.2 | 62 | - | - | - | 5.6 | 4.0 | 2.3 | ||
3.0 | 2.6 | 55 | 3.9 | 1.8 | 68 | - | - | - | - | - | - | ||
3.1 | 2.1 | 57 | - | - | - | - | - | - | - | - | - | ||
SUN23 | Suyuqlik qopqog'i 60100 | 2.0 | 24 | 44 | 2.4 | 28 | 51 | 3.4 | 38 | 72 | 1.1 | 0.7 | 2.4 |
2.1 | 18.9 | 50 | 2.5 | 23 | 59 | 3.5 | 33 | 80 | 2.1 | 1.5 | 3.0 | ||
2.2 | 14.4 | 56 | 2.7 | 18.3 | 66 | 3.7 | 28 | 89 | 2.8 | 2.0 | 3.4 | ||
2.4 | 10.6 | 63 | 2.8 | 15.1 | 74 | 3.8 | 23 | 97 | 3.7 | 3.0 | 3.6 | ||
2.5 | 7.2 | 71 | 3.0 | 11.7 | 79 | 3.9 | 19.7 | 105 | 4.9 | 4.0 | 4.0 | ||
- | - | - | - | - | - | 4.2 | 13.1 | 120 | - | - | - | ||
- | - | - | - | - | - | 4.6 | 7.2 | 138 | - | - | - | ||
SUN23B | Suyuqlik qopqog'i 40400 / | 2.1 | 18.0 | 79 | 2.7 | 19.6 | 93 | 3.5 | 27 | 112 | 1.4 | 0.7 | 3.0 |
2.2 | 15.8 | 84 | 2.8 | 17.3 | 98 | 3.7 | 25 | 116 | 2.4 | 1.5 | 3.2 | ||
2.4 | 13.6 | 89 | 3.0 | 15.2 | 103 | 3.8 | 23 | 121 | 3.0 | 2.0 | 3.4 | ||
2.5 | 11.6 | 95 | 3.1 | 13.2 | 109 | 3.9 | 21 | 126 | 3.7 | 3.0 | 3.5 | ||
- | - | - | 3.2 | 11.4 | 114 | 4.1 | 18.9 | 132 | 5.3 | 4.0 | 4.0 | ||
- | - | - | - | - | - | 4.2 | 17.0 | 137 | - | - | - | ||
- | - | - | - | - | - | - | - | - | - | - | - | ||
SU23 | Suyuqlik qopqog'i 60100 | 1.8 | 38 | 55 | 2.4 | 39 | 67 | 3.2 | 58 | 76 | 1.1 | 0.7 | 3.4 |
2.1 | 28 | 66 | 2.7 | 30 | 77 | 3.5 | 47 | 87 | 2.4 | 1.5 | 3.5 | ||
2.2 | 24 | 71 | 3.0 | 24 | 87 | 3.8 | 38 | 97 | 3.2 | 2.0 | 3.7 | ||
2.4 | 21 | 76 | 3.2 | 17.8 | 98 | 3.9 | 34 | 103 | 3.9 | 3.0 | 3.8 | ||
2.5 | 17.8 | 82 | 3.4 | 15.1 | 103 | 4.2 | 27 | 113 | 6.0 | 4.0 | 4.4 | ||
2.7 | 15.1 | 87 | 3.5 | 12.9 | 109 | 4.6 | 20 | 126 | - | - | - | ||
- | - | - | 3.7 | 10.6 | 114 | 4.9 | 14.8 | 140 | - | - | - | ||
SU43 | Suyuqlik qopqog'i 100150 | 1.8 | 56 | 117 | 2.1 | 100 | 119 | 3.0 | 126 | 140 | 1.0 | 0.7 | 3.4 |
2.0 | 40 | 133 | 2.2 | 79 | 133 | 3.1 | 110 | 151 | 1.8 | 1.5 | 3.8 | ||
- | - | - | 2.4 | 62 | 147 | 3.2 | 95 | 163 | 2.4 | 2.0 | 4.3 | ||
- | - | - | 2.5 | 48 | 162 | 3.4 | 78 | 184 | 3.4 | 3.0 | 4.6 | ||
- | - | - | 2.7 | 36 | 177 | 3.5 | 62 | 193 | 4.9 | 4.0 | 5.2 | ||
- | - | - | - | - | - | 3.7 | 48 | 210 | - | - | - | ||
- | - | - | - | - | - | 3.8 | 37 | 225 | - | - | - | ||
Buyurtma haqida ma'lumot
JN | 1/4’’ | SS | SU13A | SS |
↓ | ↓ | ↓ | ↓ | ↓ |
Burun turi | Ip hajmi | Havo qopqog'i material kodi | Püskürtme qurilmasi №. | Suyuq qopqoq material kodi |
Ilova rasmlar
Changni nazorat qilish
